智能数显仪表型号定义与外形尺寸
Intelligent Digital Display Instrument Model Definition And Dimensions

智能数显仪表 /Intelligent Digital Display Meters

智能数显仪表适用于电力电网、自动化控制系统中对电压、电流、有功功率、无功功率、视在功率、功率因数和频率等电参量的测量，油数码管 (LED) 或液
晶 (LED) 直接显示。具有显示直观、精度高、性能稳定、隔离性强、抗振动等优点。可选配多种扩展功能，包括 RS-485 通讯、开关量输入、开关量输出
和模拟量变送输出等，丰富的外型尺寸可方便地替代指针式仪表。
Intelligent digital display meters are used in electric power grid and automation control system to measure voltage, current, active power, reactive power, apparent power,
power factor and frequency which are displayed by LED or LCD. The meters have features of visual display, high precision, stable performance, strong isolation, anti-vibration
and so on. There are many optional functions, including the RS-485 communication, switching value input, switching value output and analog output. Variable dimensions can
be easily used to replace pointer instrument.

产品标准 /Product Standard

◆ GB/T 22264.1-2008 安装式数字显示电测量仪表第 1 部分：定义和通用要求；
◆ GB/T 22264.2-2008 安装式数字显示电测量仪表第 2 部分：电流表和电压表的特殊要求；
◆ GB/T 22264.3-2008 安装式数字显示电测量仪表第 3 部分：功率表和无功功率表的特殊要求；
◆ GB/T 22264.4-2008 安装式数字显示电测量仪表第 4 部分：频率表的特殊要求；
◆ GB/T 22264.5-2008 安装式数字显示电测量仪表第 5 部分：相位表和功率因数表的特殊要求；
◆ GB/T 22264.8-2008 安装式数字显示电测量仪表第 8 部分：推荐的试验方法。
◆ GB/T 2264.1-2008 Mounted digital display electric measuring instruments-part1: Definitions and general requirements common to all parts;
◆ GB/T 2264.2-2008 Mounted digital display electric measuring instruments-part2: Special requirements for ammeters and voltmeters;
◆ GB/T 2264.3-2008 Mounted digital display electric measuring instruments-part3: Special requirements for watt meters and varmeters;
◆ GB/T 2264.4-2008 Mounted digital display electric measuring instruments-part4: Special requirements for frequency meters;
◆ GB/T 2264.5-2008 Mounted digital display electric measuring instruments-part5: Special requirements for phase meters and power factor meters;
◆ GB/T 2264.8-2008 Mounted digital display electric measuring instruments-part8: Recommended test methods.
