干式变压器系列
Dry-type transformers series

环保干式变压器

Environmental Protection Dry transformer

SGB(H)10 型

概述 / Product overview 型号含义 / Model and meaning

SGB(H)10 型 H 级绝缘干式电力变压器承受热冲击能力强，过负载能 S G B (H) 10 - □ / 10
力大、难燃，防火性能高、低损耗、局部放电量小、噪声低、不产生
有害气体、不污染环境、对湿度不敏感、体积小、不开裂、 维护简便。
因此最适宜于防火要求高、负荷波动大以及污秽潮湿的恶劣环境中。 高压侧电压等级
如机场、发电厂、冶金作业、医院、高层建筑、购物中心、居民密集 High side voltage level
区以及石油化工、核电站、核潜艇等特殊环境中。 额定容量
SGB (H) 10 type H-class insulation dry-type power transformers ability Rated Capacity
to withstand thermal shock, overload capacity, high flame retardant, fire 设计序号
Design No.
resistance, low loss, low partial discharge capacity, low noise, no harmful
gases, do not pollute the environment , insensitive to humidity, small, 绝缘等级
Insulation Class
no cracking, easy to maintain. Therefore most suitable fire protection
requirements high load fluctuation and dirty wet harsh environments. Such as 低压“箔”式线圈
Low pressure "foil" coil
airports, power plants, metallurgical operations, hospitals, high-rise buildings,
shopping centers, densely populated areas as well as petrochemical, nuclear 空气
air
power plants, nuclear submarines and other special environment.
三相
Three Phase
