设备线夹 /Terminal connector

用途 /Application
设备线夹主要用于变电所母线引下线与电气设备(如变压器、断路器、隔离开关、穿墙套管等)的出线端子接续，因常用电气设备的出线端子有铜质和铝质两类，
而母线引出线分为铝绞线或钢芯铝绞线，故设备线夹从材质上分为铝设备线夹和铜铝过渡设备线夹两个系列。根据安装方法和结构形式的不同，设备线夹分
螺栓型、压缩型两种类型。每种型式的线夹又按引下线与安装电气设备端子所成角的不同分为 0° 30° 90°三种。
DTL 系列铜铝接线端子适用于配电装置铝芯电缆与电气设备铜端的过渡连接；DL 铝端子用于铝芯电缆与电气设备的铝端连接；DT 铜端子用于铜芯电缆与
电气设备铜端连接。我公司另有采用爆炸焊工艺生产的铜铝接线端子和设备线夹，具有焊缝强度高，电气性能优良，抗电化腐蚀，使用寿命长，不会断裂，
安全性高的特点。

TerminAI connectors are used to connect tap conductor to power equipments (transformer,circuit breaker,disconnet switch.etc)or to wAII bushing of substation.Aluminum
connectors are Also used to connect the tap conductor of T-connector.The connectors inclede conpressive-type and bolted,both types have angle of 0°、30° and90° with
the direction of tap conductor.
DTL series Al-Cu connection terminAI is suitable for transition joint of distribution device Aluminium core cable and electric equipment. DL Aluminium is used for Aluminium
terminAI linking of Aluminium core cable and electric equipment.DT copper terminAI is used for copper terminAI electric equipment.DT copper terminAI is used for copper
terminAI linking of copper core cable and electric equipment,The products adopt friction welding workmanship,Our company supplies Cu-AI terminAI and wire clamp made
by explosive wedling technique.The products have features as high welding strength, excellent electric property, resistance to gAlvanic corrosion, long service life, never
fracture,high safety, etc.

DT、DL 铜、铝接线端子 DTLB 铜铝接线端子 ( 爆炸焊 ) DTL 铜铝接线端子
DT,DL copper Aluminium DTLB Cu-AI connecting terminAI DTL Cu-AI connecting terminAI
connecting terminAl (explosive wedging)

GT-G、GL-G 铜、铝连接管 DTL 铜铝连接管 DTL-2 铜铝接线端子 ( 出口型 )
GT-G，GL-A AI-Cu connecting tube DTL Cu-AI connecting tube DTL-2 BimetAllic compression Lug

GTY 铜接线管 GTGA 窥口铜接线端子
GTY copper connecting tube DTGA spy hole copper connecting terminAI
