架空绝缘导线金具
Overhead Insulated Wire Fittings

JXLD 系列楔型接地线夹及绝缘罩

JXLD series wedge grounding clamp and insulation cover

选型表一 Selection table (LGJ、JKLGYJ 导线 )
C
主导线 支导线
规格型号 接地线夹 绝缘罩
产品名称 备注 Main lead Lead wire
product name Specifications Remarks LGJ LGJ Ground Insulation
Model clamp cover 架空绝缘导线金具
(JKLGYJ) (JKLGYJ)
JXD-1 35~50 35~50
JXD-2 JXL-1 70~95 35~50 JXLD-1 JXD-1/2(Z)
JXD-3 70~95 70~95
楔型并沟线夹 JXD-4 120~150 35~50
( 弹射芯 )
Wedge-type JXD-5 JXL-3 120~150 70~95 JXLD-3 JXD-3/4(Z)
and groove JXD-6 120~150 120~150
clamp (ejector
core) JXD-7 185~240 35~50
JXD-8 185~240 70~95
JXL-4 JXLD-4 JXD-3/4(Z)
JXD-9 185~240 120~150
JXD-10 185~240 185~240

选型表二 Selection table (LJ(TJ)、JKLGYJ 导线 )

主导线 支导线
规格型号 绝缘罩
产品名称 Specifications 备注 Main lead Lead wire 备注 Insulation
product name Remarks LJ(TJ)、 LJ(TJ)、 Remarks
Model cover
JKLYJ JKLYJ
JXD-1 35~50 35~50
JXD-2 JXL-1 70~95 35~50 JXLD-1 JXD-1/2(Z)
JXD-3 70~95 70~95
楔型并沟线夹 JXD-4 120~150 35~50
( 弹射芯 )
Wedge-type JXD-5 JXL-2 120~150 70~95 JXLD-2 JXD-1/2(Z)
and groove JXD-6 120~150 120~150
clamp (ejector
core) JXD-7 185~240 35~50
JXD-8 185~240 70~95
JXL-3 JXLD-3 JXD-3/4(Z)
JXD-9 185~240 120~150
JXD-10 185~240 185~240
注：接地线夹必须使用硅橡胶绝缘罩！
Note: The grounding clamp must use silicone rubber insulation cover!
