10kV SCBH15、SGBH16 博大变压器
非晶合金干式变压器
Amorphous alloy dry type transformer BODA TRANSFORMER

产品介绍
Product introduction
本公司运用成熟技术开发设计的 SCBH15、SGBH16 型非晶合金干式变压器，性能优越，
产品安全、可靠、环保，可深入负荷中心，适应高密度负荷的现代化大城市发展的需要。
该产品大幅度降低了空载损耗、负载损耗，是当今世界最先进的干式变压器。
本产品具有阻燃、自熄、耐潮、抗潮、抗裂和免维护等优点，可广泛用于高层建筑、
商业中心、地铁、机场、车站、工矿企业和发电厂，特别适合于易燃、易爆等防火要
求高的场所安装使用。

Our company utilizes the mature technical development design SCBH15, SGBH15
amorphous alloy dry type transformer,the performance is superior, product safe,
reliable, environmental protection, but shoulders the center thoroughly, the
adaptation high density load modernization big urban development need.This
product reduced the idling to lose, the load large scale loses,is now the world most
advanced dry type transformer.
This product has being flame-resistant, from extinguishes,bears the tide, the
moisture resistant, the anti-crack and exempts merits and so on maintenance,
but widely uses in the high-rise construction, the business center, the subway, the
airport,the station, the industry and mining enterprise and the power plant, suits
specially in flammable, explosive and so on the fire protections requests the high
place to install the use.

产品特点
10kV SCBH15、SGBH16 Characteristics of the product
非晶合金干式变压器
Amorphous alloy dry type transformer 本铁芯由非晶合金带材卷制而成，采用矩形截面，三相五柱结构或三相三柱结构，空
载损耗比普通的干式变压器降低四分之三，节能效果显著。
型号含义 低压线圈采用铜箔绕制，高压线圈采用环氧树脂经真空浇注而成或者选用 Nomex 绝
The meaning of model 缘材料，采用连续式结构，并经 VPI 真空加压设备多次浸渍 H 级无溶剂绝缘、高温烘
焙固化，机械强度高，散热效果好，承受短路能力强。
S C (B) H 15 - □ / □
1. 阻燃、防爆、不污染、防火等级高。
2. 噪音低、体积小、安装简单、免维护。
电压等级
Voltage grade (kV) 3. 局部放电量小、绝缘水平高、产品使用寿命长。
4.“三防”能力极佳，无龟裂现象。
额定容量
Rated capacity (kVA) 5. 本产品寿命期后能分解回收，永不污染环境。
6. 过载能力强，120% 负载下可长期安全运行。
性能水平代号
performance level code-name
非晶合金 This ferrite core becomes by the crystalless alloy strip volume system,uses the
rectangular cross-section,three-phase five column or three-phase five column
Amorphous alloy
structure,the idling loses compared to the ordinary dry transformer reduces
低压可采用箔式线圈 3/4,energy conservation effect is remarkable.The low-voltage winding uses the
Low pressure can use foil coil copper foil to circle the system,the secondary winding uses epoxy resin to become or
to select Nomex insulation mateerial after the vacuumcasting,uses the continuous-
环氧树脂浇注型 type strcture,and soaks H level non-solvent insulation,high temperature many times
Epoxy resin cast after the VPI vacuum compression equipment cures the solidification,mechanical
三 相 strength is high,radiates the effect to be good,withstanding short circuit ability.
Three-phase 1.Being flame-resistant, explosion-proot does not pollute, fire protection rank is high.
2.The noise is low, volume is small, installment is simple, exempts the maintenance.
3.Partial discharge capacity is small, insulation level is high, and product service life is long.
4."three-protection " ability is extremely good, non-chap phenomenon.
5.After this product average life can decompose the recycling, never pollutes the www.cnboda.cn
6.overload capacity, under 1 20% load may operate for a long-term and safely.
