电站金具
Power Station Fittings

电站金具

Substation fitting

电站金具亦称大电流金具。包括在发电厂、变电所的变配电装置、支持软导线、复导线及各种硬母线的金具。按所用母线类形分为矩形、槽形、管形母线和
软母线固定金具。
产品型号中字母和数字的意义为：M- 母线；N- 户内；W- 户外；P- 平放；L- 立放；G- 管形、间隔；J- 矩形；C- 槽形；D- 吊挂、单母线；S- 双母线；
Y- 圆；H- 环数字表示母线大小、数量或序号。
适用电压在 330kV 及以上的固定金具。在 1.05 倍最高运行电压下无可见电晕。
Bus-bar supports are used to fix or hang bus-bars on insulators at the substation, including rectangular channel, tube bus and cable supports in
accordance with bus type.
The meaning of letter & arabic figures in the catalog are shown as follow:M-bus W-outdoor G-tubular spacer Y-round P-horizontal mounting
J-rectangular C-channel N-indoor D-hanging single-cable S-double bus H-ring L-vertical mounting. The arabic figures show piece, size of bus and
order.
Visible corona for system voltage up to 330KV or higher, test voltage should be 1.05 of the max, operating voltage of the system

MNL 户内矩形母线固定金具 MWL 户外矩形母线固定金具 MNP 户内矩形母线固定金具 MWP 户外矩形母线固定金具
MNL indoor support for MWL outdoor support for MNP indoor support for MWP outdoor support for
rectangular bar rectangular bar rectangular bar rectangular bar

MJG 矩形母线间隔垫 MCN 槽形母线固定金具 MCW 槽形母线固定金具 MCG 槽形母线间隔垫
MJG spacers for rectangular bar MCN supports for channel bar MCW supports for channel bar MCG spacers for channel bar

MGD 端部固定金具 MDG 单导线固定金具 MDU 管母线悬挂金具 MGXX 管母线悬挂金具
MGD supports for end fixing MDG supports for single conductor MDU suspending fitting for MGXX suspending
tubular bus fitting for tubular bus

MSG 双软母线固定金具 MSG 双软母线固定金具 MGG 管形母线固定金具 ( 滑动式、固定式 ) MGGHZ 固定金具 ( 滑动支撑 )
MSG supports for double cables MSG supports for double cables MGG supports for tubular bus MGGHZ bus-bar supports(sliding
support)
173
