架空绝缘导线金具
Overhead Insulated Wire Fittings

FDL/FHJ 系列防雷金具

FDL /FHJ series of mine with gold

产品结构 /product structure
穿刺型防雷金具，由穿刺电极、接地电极和绝缘罩三部分组成，用于 10kV、20kV 的绝缘导线雷击断线的保护。
Puncture-type lightning protection fittings, by the puncture electrode, grounding electrode and insulating
cover composed of three parts, for 10kV, 20kV insulated wire lightning protection.

规格及技术参数 /Specifications and technical parameters

FDL-A/B 产品型号 导线电压等级 适应导线
Product number Conductor voltage rating Adapt to the wire
FDL-50-240A JKLYJ10KV 50~240
FDL-50-240B JKLYJ10KV 50~240
FHJ-50-240A JKLYJ10KV 50~240
FHJ-50-240B JKLYJ10KV 50~240
FDL-16-120D JKLYJ10KV 16~120
FDL-50-240D JKLYJ10KV 50~240
FDL-16-120E JKLYJ10KV 16~120
FDL-50-240E JKLYJ10KV 50~240
注：A 代表穿刺型，B 代表非穿刺。Note: A on behalf of puncture, B on behalf of non-puncture.
FHJ-A/B

适用绝缘子及安装参数表 /Applicable insulators and installation parameters table

PS-
绝缘子型号 P-10T P-15T FPQ3-10 FPQ4-10 P-20T PS-15T/300
15T/500
对应的距离 D 300±10 300±10 300±10 300±10 300±10 230±10 230±10
对应的距离 L 80±5 90±5 90±10 120±10 120±10 120±10 120±10

安装示意图 /Installation diagram

FDL-D

፬᎟ଥᏌ +PUWNCVKQP IWCTF
רօᚬ෽
2TGUUWTG PWVU & ៦ᕮҊ .QCF UKFG
ቯըჇ೟
(43
᪢᫮஡ݤၟ .
৔ড়ᒵ .KIJVPKPI RTQVGEVKQP
#TEKPI CTO ITQWPFKPI TKPI
፬᎟ࢅᧁᑿ
නଳ +PUWNCVQT UVGGN HGGV
%TQUU CTO
FDL-E ኪίЪ᪢᫮஡ݤፏߵ ኪϷЪ᪢᫮஡ݤፏߵ
6JG HKTUV IGPGTCVKQP QH NKIJVPKPI RTQVGEVKQP CPF ITQWPFKPI ENCOR 6JG UGEQPF IGPGTCVKQP NKIJVPKPI RTQVGEVKQP CPF ITQWPFKPI ENCOR

065
