高压开关柜系列
High Voltage Switchgear Series
铠装移开式交流金属封闭开关设备
Armored remove AC metal-enclosed switchgear
KYN28A-12
概述 / Product overview 型号含义 / Model and meaning
KYN28A-12(Z)(GZS1) 铠装移开式交流金属封闭开关设备 ( 以下简 K Y N 28A - 12 Z
称“开关设备”) 它适用于三相交流 50Hz 电力系统，用于接受和分
配电能并对电路实行控制、保护及监测。
本产品符合标准：GB3906《3~35kV 交流金属封闭开关设备》、 真空断路器
GB/T11022《高压开关设备和控制设备标准共用技术要求》、 Vacuum Circuit Breaker
额定电压
IEC60298《额定电压1kV及以上交流金属封闭开关设备和控制设备》。 Rated voltage (kV)
KYN28A-12(Z) (GZS1) type armored remove AC metal-enclosed switchgear 设计序号
(hereinafter referred to as "switching equipment") which applies to three- Design No.
phase AC 50Hz power system for receiving and distributing power and circuit 户内
implementation of control, protection and monitoring. Indoor
移开式
This product meets the standards: GB3906 "3 ~ 35kV AC metal-enclosed Removable
switchgear", GB / T11022 "high-voltage switchgear and control equipment 金属铠装式
standards common technical requirements", IEC60298 "rated voltage 1kV and Metal sheathed
above AC metal-enclosed switchgear and control equipment."
