高压开关柜系列
High Voltage Switchgear Series 青 岛 特 变
铠装移开式交流金属封闭开关设备
Armored remove AC metal-enclosed switchgear
KYN61-40.5
概述 / Product overview 型号含义 / Model and meaning
KYN61-40.5(Z) 铠装移开式交流金属封闭开关设备 ( 以下简称“开 K Y N 61- 40.5 □ / □ □
关设备”) 它适用于三相交流 50Hz 电力系统，用于发电厂、变电所
及工矿企业的配电室接受和分配电能之用，并对电路实行控制、保护 额定短路开断电流 (kA)
及监测。 Rated short-circuit breaking
current (kA)
本产品符合标准：GB3906《3~35kV 交流金属封闭开关设备》， 额定电流
GB/T11022《高压开关设备和控制设备标准共用技术要求》、 Rated current
断路器种类 Z 真空 SF6 六氟化硫
IEC60298《额定电压 1kV 以上及 50kV 以下交流金属封闭开关设备 Z sulfur hexafluoride SF6 vacuum circuit
和控制设备》。 breaker typesMetal sheathed
额定电压 (kV)
KYN61-40.5 (Z) type armored remove AC metal-enclosed switchgear Rated voltage (kV)
(hereinafter referred to as "switching equipment") which applies to three-phase 设计序号
AC 50Hz power system for power plants, substations and industrial and mining Design No.
enterprises distribution room acceptance and distribution of electric energy 户内
use, and circuit implementation of control, protection and monitoring. Indoor
This product meets the standards: GB3906 "3 ~ 35kV AC metal-enclosed 移开式
switchgear", GB / T11022 "high-voltage switchgear and control equipment Removable
standards common technical requirements", IEC60298 "rated voltage above 金属铠装式
1kV and 50kV ac metal-enclosed switchgear and control equipment . " Metal sheathed
