WANGYUAN 接续金具
ELELCTRIC TECHNOLOGY Ltd. Splicing Fitting

四变二线夹

Connectors for 4-2 bundle conductors A

适用母线 主要尺寸 Main
Conductor bus Dimensions
型号 参考重量

 Catalog No. 四导线 二导线 Weight (kg)
Four-bundle Two-bundle Φ1 Φ2 配变电金具 Hotels substation fittings
conductor conductor
JTY-2/4-300/40-900K LGJ-300/40 LGKK-900 23.94 49.00 24.0
JTY-2/4-300/40-1400 LGJ-300/40 LGJQT-1400 23.94 51.00 24.8
JTY-2/4-300/40~1440N LGJ-300/40 NAHLGJQ-1440 23.94 51.36 25.5
JTY-2/4-400/50-900K LGJ-400/50 LGKK-900 27.63 49.00 24.0
 JTY-2/4-400/50~1400 LGJ-400/50 LGJQT-1400 27.63 51.00 24.8
JTY-2/4-400/50-1440N LGJ-400/50 NAHLGJQ-1440 27.63 51.36 25.5
注：四导线、引下两导线可根据用户实际需要进行订货，订货时请注明导线型号。
Note:four leads and another two leads could be ordered according to the customers practical demand，the consumer should give
clear indication of the lead kind.

四变二线夹
Connectors for 4-2 bundle conductors

适用母线 主要尺寸 Main
Conductor bus Dimensions
型号 参考重量
Catalog No. 四导线 二导线 Weight (kg)
Four-bundle Two-bundle Φ1 Φ2
 conductor conductor
JR-2/4-300/40-900K LGJ-300/40 LGKK-900 23.94 49.00 25.0

JR-2/4-300/40-1400 LGJ-300/40 LGJQT-1400 23.94 51.00 26.5
JR-2/4-300/40-1440N LGJ-300/40 NAHLGJQ-1440 23.94 51.36 27.0
JR-2/4-300/50-900K LGJ-400/50 LGKK-900 27.63 49.00 25.0

JR-2/4-400/50-1400 LGJ-400/50 LGJQT-1400 27.63 51.00 26.5
JR-2/4400/50-1440N LGJ-400/50 NAHLGJQ-1440 27.63 51.36 27.0

注：四导线、引下两导线可根据用户实际需要进行订货，订货时请注明导线型号。
Note:four leads and another two leads could be ordered according to the customers practical demand，the consumer should give
clear indication of the lead kind.

六变二线夹
Connectors for 6-2 bundle conductors

# & #&
 型号 适用母线 Conductor bus 参考重量
Catalog No. Weight (kg)
$ ' $' L Φ
JR-2/6-240/30-1440N 400 750 40
% ( %( JR-2/6-300/40-1440N 400 750 46
JR-2/6-400/50-1600K 400 800 55
. JR-2/6-300/50-1600K 400 800 55
注：六导线、引下两导线可根据用户实际需要进行订货，订货时请注明导线型号。
Noterfour leads and another two leads could be ordered according to the customers practical demand, the consumer should give
clear indication of the lead kind.
