防爆活接头系列
Explosion-proof union series

BHJ
ٝЕࠃࢤ๨ ̵͙͙͑a̶͖͑͝ḤḤ
͒΅ͽ͹ͼ΀Ͷͼͻ̺ͽͿͼͼͳḤ΂ͻͶͼͻḤ̵͙͙̹͑Ḥ̶͖͑͝
྘ݼݣၬ ͚ͼͱͲ͹ḤͺͲͮͻͶͻʹ
BHJ - □ - □ □ □ □

材质（I：碳钢（可不注）II：不锈钢）
Material (I: carbon steel (can not be) II: stainless steel)
螺纹规格（非标产品请注明）
Thread specifications (please specify non- standard products)
结构形式（A：两端内螺纹；B：一端内一端外螺纹；C：两端外螺纹）
Structural form (A: internal thread at both ends; B: inner end at one end external thread; C: external thread at both ends)
螺纹规格（正标产品请注明）
Thread specifications (please specify the product)
I：活接头；II：管接头；III：变径接头
I: union; II: pipe joint; III: reducer
防爆活接头
Explosion-proof union

Ӂ௖หׄḤḤ ͓Ͳͮ΁΂ͿͲ΀ Features

◆ 防爆采用不锈钢制作，或油脂碳素钢电镀处理； ◆ Explosion-proof is made of stainless steel, or greased carbon
steel plating treatment;
◆ 螺纹尺寸规格可根据用户要求特殊加工，如 NPT 螺纹、英制以及
◆ Thread size specifications can be specially processed
公制螺纹等；
according to user requirements, such as NPT thread, inch
◆ 两种不同材质可供选择。 and metric thread;
◆ Two different materials to choose from.

ൡႨٓຶḤḤ ͠ͰͼͽͲḤͼͳḤͮͽͽ͹ͶͰͮ΁Ͷͼͻ Scope of application
◆ 适用于爆炸性气体环境 1 区、2 区； ◆ Applicable to Zone 1 and Zone 2 of explosive gas
environment;
◆ 适用于可燃性粉尘环境 20 区、21 区、22 区；
◆ Applicable to flammable dust environment in Zone 20, Zone
◆ 适用于 IIA、IIB、IIC 级爆炸性气体环境； 21 and Zone 22;
◆ 适用于温度级别为 T1~T6 的环境； ◆ Applicable to IIA, IIB, IIC explosive gas environment;
◆ 适用于是有采炼、储存、化工、医疗、军工级军事设施等爆炸性危 ◆ Suitable for environments with temperature levels from T1 to
险环境； T6;
◆ Applicable to explosive hazardous environments such as
◆ 产品主要作为产品与钢管布线系统中的连接之用。
mining, storage, chemical, medical, military-grade military
facilities;
◆ The product is mainly used as a connection between the
product and the steel pipe wiring system.
