电抗器系列
Reactor series

规格参数 / Specification parameter

外形尺寸 安装地脚尺寸
额定容量 额定电压 电感 额定电流 Outline dimension Install anchor size
型号 Rated capacity Rated voltage Inductance Rated current (mm) (mm)
Model
（kvar） (kV) (mH) (A)
L W H A B

CKSCFL-10-58-38.2 121 10 38.2 58 1100 450 1260 580 320

CKSCFL-10-173-12.73 359 10 12.73 173 1400 550 1650 600 500

CKSCFL-10-462-1.99 400 10 1.99 462 1450 600 1400 800 500

CKSCFL-10-577-3.82 1199 10 3.82 577 1800 700 1600 1110 600

CKSCFL-10-693-2.65 1199 10 2.65 693 1800 700 1750 1110 600

订货须知 / Order notice

订货时需提供以下参数： The following parameters should be provided when ordering:
系统电压 system voltage
额定电流 Rated current
Rated inductance or reactance
额定电感或电抗 Allow long-term over current multiple
允许长期过电流倍数
If the capacitor is connected in series with the reactor, the following parameters
如果是电容器用串联电抗器，还需提供以下参数： are also required:
配套电容器组的三相容量 QC(kvar) Three phase capacity QC (kvar) of matching capacitor group
Rated phase voltage Ucn (kV) of the auxiliary capacitor
配套电容器的额定相电压 Ucn(kV) Reactance rate K (%)
电抗率 k(%) Whether there is harmonic
是否有谐波

Generally, the parameters of the capacitor group are determined, and the
一般情况下，上述电容器组的参数确定后，可以计算电抗器的参数：
parameters of the reactor can be calculated:

Q C
额定电流：I n □ (A) Rated current:I n □ (A)
Q C
3 □U cn 3 □ U cn

额定端电压：U n □10□k□U cn (V) Rated terminal voltage:Un □ 10 □ k □ U cn (V)

Rated capacity (San Xiang):Sn □ (kvar)
k □ Q cn
k□Q cn
额定容量 ( 三相 )：S n □ (kvar) 100
100 U n 30 □ K □ Qcn
2
2 Rated reactance value:Xn □ ( □ ) 或 Xn □
额定电抗值：X n □ ( □ ) 或 X n □ 30□K□Q cn I n Q cn
U n
X
I n Q cn Rated electric drive:Ln □ □ 1000(mH)
X 100 □
额定电感：L n □ □ 1000(mH)
100 □
