WANGYUAN 设备线夹
ELELCTRIC TECHNOLOGY Ltd. Terminal connector

螺栓型铜铝过渡设备线夹 (A 型钎焊 )

Aluminium-Copper terminAI Clamps(typeA Bolted) A

适用导线 主要尺寸 Main Dimensions
型号 Suitable
. Catalog No. 2
Conductor(mm ) A B L H
SLG-1AQ 35-50 40 6 65 65 配变电金具 Hotels substation fittings
#N
SLG-2AQ 70-95 40 6 80 80
SLG-3AQ 120-150 50 7 125 125
* %W
SLG-4AQ 185-240 50 7 125 125
线夹本体为铝制件，其余为热镀锌钢制件。
# $
The clamp body are Aluminium，the other parts are hot-dip gAlvanized steel.

螺栓型铜铝过渡设备线夹 (B 型钎焊 )
Aluminium-Copper terminAI Clamps(typeB Bolted)

. 适用导线 主要尺寸 Main Dimensions
型号 Suitable
#N Catalog No. Conductor(mm ) A B L H
2
SLG-1BQ 35-50 40 6 65 65
*
%W SLG-2BQ 70-95 40 6 80 80
$ SLG-3BQ 120-150 50 7 125 125
d
SLG-4BQ 185-240 50 7 125 125
#
线夹本体为铝制件，其余为热镀锌钢制件。
The clamp body are Aluminium, the other parts are hot-dip gAlvanized steel.

螺栓型铜铝过渡设备线夹 (C 型钎焊 )
Aluminium-Copper terminAI Clamps(typeC Bolted)

. 适用导线 主要尺寸 Main Dimensions
型号 Suitable
Catalog No. 2
Conductor(mm ) A B L H
#N $
SLG-1CQ 35-50 40 6 65 65
# * SLG-2CQ 70-95 40 6 80 80
SLG-3CQ 120-150 50 7 125 125
%W
SLG-4CQ 185-240 50 7 125 125
线夹本体为铝制件，其余为热镀锌钢制件。
The clamp body are Aluminium, the other parts are hot-dip gAlvanized steel.
