功能单元 插接箱单元

FUNCTION UNIT Jack box unit

艾博插接箱，其设计结构紧凑、外形美观、性能可靠，额定电流 为
16A~1600A，每种电流等级可提供各种不同外形尺寸，设计更贴切用户需求。

AI BO jack box is compact in design structure, beautiful in appearance, reliable in property,
with rated current of 16A~1600A. Each current level can provide different sizes, and its
design is more suitable for customer’ s demands.

内部配置

根据用户对插接箱的配置要求，可以在插接箱内安装3极或4极断路器对负载进
行保护，断路器可配备ABB开关，也可由用户自行选择，包括保护开关的附
件，比如操作手柄、分励脱扣、热磁脱扣、漏电保护模块等，公司将按照用户
的要求提供标准配置。同时公司可以在现场测量后，参照现场具体情况对插接
箱的外形尺寸进行非标设计，以满足现场的要求。

Internal configuration

According to customer’ s needs on the configuration of jack box, we can install 3-pole
or 4-pole circuit breaker inside the jack box to protect load; the circuit breaker can be
equipped with ABB switch, and also can be chosen by customers themselves, including
accessories protecting the switch, such as operation handle, shunt trip, thermal magnet-
ic trip and leakage protection module. The company will provide standard configuration
according to customer’ s requirement. At the same time, the company may design non
standard types by referring to the specific site condition for the appearance size of jack
box after on-site measurement, so as to meet on-site requirement.
